Heater Hoses (Nitra Plant Build) (3.0L Dohc Gdi Sc V6 Petrol, Less Auxiliary Coolant Pumps, With...

Land Rover Discovery 5 (2017+) [3.0 Diesel 24V DOHC TC]

Find Your Part

Land Rover Discovery 5 (2017+) [3.0 Diesel 24V DOHC TC] - Heater Hoses (Nitra Plant Build) (3.0L DOHC GDI SC V6 PETROL, Less Auxiliary Coolant Pumps, With...

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR011270 SCREW $1.25 IN STOCK
Photo Part No Description Price (each) Stock
KYG500380 SCREW AND WASHER - HEX HEAD $0.36 IN STOCK
Photo Part No Description Price (each) Stock
LR061621 BOLT $1.70 To Order
Photo Part No Description Price (each) Stock
LR010793 GASKET - WATER MANIFOLD $9.67 To Order
Photo Part No Description Price (each) Stock
LR034616 HOSE - HEATER WATER $26.12 To Order
Photo Part No Description Price (each) Stock
LR034597 TUBE - HEATER WATER $50.14 To Order
Photo Part No Description Price (each) Stock
LR041442 SENSOR - ENGINE COOLANT TEMPERATURE $47.53 To Order
Photo Part No Description Price (each) Stock
LR122710 MANIFOLD - HEATER $142.97 To Order
Photo Part No Description Price (each) Stock
LR034624 HOSE AND BRACKET - HEATING $100.66 To Order
View All
Heater Hoses (Nitra Plant Build) (3.0L DOHC GDI SC V6 PETROL, Less Auxiliary Coolant Pumps, With Fresh Air Heater, With Ptc Heater) ((V) FROMK2000001) of Land Rover Land Rover Discovery 5 (2017+) [3.0 Diesel 24V DOHC TC] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HS1 LR011270
SCREW
M6 x 25MM, Torx / From: K2000001
IN STOCK 		$1.25 4
HS2 KYG500380
SCREW AND WASHER - HEX HEAD
Hexagonal Head, M6 X 13.5MM / From: K2000001
IN STOCK 		$0.36 2
HS3 LR061621
BOLT
M10 x 16MM / From: K2000001 		$1.70 1
12A648 LR041442
SENSOR - ENGINE COOLANT TEMPERATURE
From: K2000001 		$47.53 1
18N349 LR122710
MANIFOLD - HEATER
Heater, Tube From Engine Block To Heater Inlet Hose, With Sensor / From: K2000001 		$142.97 1
8255 LR010793
GASKET - WATER MANIFOLD
From: K2000001 		$9.67 2
18472 LR034616
HOSE - HEATER WATER
From: K2000001 		$26.12 1
18663 LR034597
TUBE - HEATER WATER
From: K2000001 		$50.14 1
721488 LR034624
HOSE AND BRACKET - HEATING
From Engine Block To Heater Inlet Hose / From: K2000001 		$100.66 1
