Name: Anti-Lock Braking System (ABS Modulator)
Rating: 4.7 (1 reviews)

Anti-Lock Braking System (ABS Modulator) of Land Rover Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol]

View All

Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol] - Anti-Lock Braking System (ABS Modulator)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR033469	BOLT	$1.56	To Order

Photo	Part No	Description	Price (each)	Stock
	LR027995	NUT	$1.02	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4648959	SCREW	$4.12	To Order

Photo	Part No	Description	Price (each)	Stock
	LR011889	SCREW	$4.04	To Order

Photo	Part No	Description	Price (each)	Stock
	LR033466	BRACKET - ABS MODULATOR	$44.81	To Order
	LR033467	BRACKET - ABS MODULATOR	$42.98	To Order

Photo	Part No	Description	Price (each)	Stock
	LR033468	MODULATOR - ABS	$2,476.41	To Order
	LR045796	MODULATOR - ABS	$2,650.23	To Order
	LR042104	MODULATOR - ABS	$1,561.35	To Order

...and 33 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	LR033469	BOLT	LR033469 BOLT Hexagonal Head, M10 X 17	$1.56	1
HN1	LR027995	NUT IN STOCK	LR027995 NUT M6 X 0.7 - 4, Nut "U" Spring IN STOCK	$1.02	3
HS1	4648959	SCREW	4648959 SCREW M6 X 20MM, Torx	$4.12	2
HS2	LR011889	SCREW	LR011889 SCREW M6 x 29MM, Torx	$4.04	3
2C325	LR033466	BRACKET - ABS MODULATOR	LR033466 BRACKET - ABS MODULATOR LHD	$44.81	1
2C325	LR033467	BRACKET - ABS MODULATOR	LR033467 BRACKET - ABS MODULATOR RHD	$42.98	1
2M110	LR033468	MODULATOR - ABS	LR033468 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / To: DA105107	$2,476.41	1
2M110	LR045796	MODULATOR - ABS	LR045796 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: DA105108 / To: DA999999	$2,650.23	1
2M110	LR042104	MODULATOR - ABS	LR042104 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: EA000001 / To: EA143391	$1,561.35	1
2M110	LR056059	MODULATOR - ABS	LR056059 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: EA143392 / To: EA999999	$2,476.90	1
2M110	LR045971	MODULATOR - ABS	LR045971 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 HEV 4WD / ABS / From: FA000001 / To: FA100000	$2,317.63	1
2M110	LR061890	MODULATOR - ABS	LR061890 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: FA000001 / To: FA212940	$3,493.93	1
2M110	LR061898	MODULATOR - ABS	LR061898 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 HEV 4WD / ABS / From: FA100001 / To: FA999999	$3,277.63	1
2M110	LR071810	MODULATOR - ABS	LR071810 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 HEV 4WD / ABS / From: GA000001 / To: GA999999	$3,434.50	1
2M110	LR070405	MODULATOR - ABS	LR070405 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: GA000001 / To: GA264555	$3,375.38	1
2M110	LR069996	MODULATOR - ABS	LR069996 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: FA212941 / To: FA221545	$3,425.23	1
2M110	LR079257	MODULATOR - ABS	LR079257 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: GA264556 / To: GA284903	$3,324.28	1
2M110	LR081197	Modulator	LR081197 Modulator 8 Speed Auto Trans ZF 8HP45 / ABS / From: FA221546 / To: FA264852	$3,654.03	1
2M110	LR081707	MODULATOR - ABS	LR081707 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: FA264853 / To: FA999999	$3,425.12	1
2M110	LR082227	MODULATOR - ABS	LR082227 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: GA284904 / To: GA291589	$3,407.41	1
2M110	LR084890	MODULATOR - ABS	LR084890 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: GA291590 / To: GA999999	$2,869.62	1
2M110	LR084561	MODULATOR - ABS	LR084561 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: HA000001 / To: HA341754	$3,545.01	1
2M110	LR100363	MODULATOR - ABS	LR100363 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: HA341755 / To: HA379095	$3,243.33	1
2M110	LR084407	MODULATOR - ABS	LR084407 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 HEV 4WD / ABS / From: HA000001 / To: HA999999	$3,390.73	1
2M110	LR115165	MODULATOR - ABS	LR115165 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: JA000001 / To: JA398595	$2,499.65	1
2M110	LR115763	MODULATOR - ABS	LR115763 MODULATOR - ABS 8HP Gen3 Hybrid Trans / ABS / From: JA000001 / To: JA501891	$3,046.99	1
2M110	LR119175	MODULATOR - ABS	LR119175 MODULATOR - ABS 8HP Gen3 Hybrid Trans / ABS / From: JA501892 / To: JA503692	$2,789.63	1
2M110	LR159939	MODULATOR - ABS	LR159939 MODULATOR - ABS 8HP Gen3 Hybrid Trans / ABS / From: KA000001 / To: KA554777	$3,114.29	1
2M110	LR117873	MODULATOR - ABS	LR117873 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: KA000001 / To: KA566977	$2,412.07	1
2M110	LR128882	MODULATOR - ABS	LR128882 MODULATOR - ABS 8HP Gen3 Hybrid Trans / ABS / From: JA503693 / To: JA999999	$2,981.08	1
2M110	LR126763	MODULATOR - ABS	LR126763 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 HEV 4WD / ABS / From: JA398596 / To: JA418595	$2,678.66	1
2M110	LR126764	MODULATOR - ABS	LR126764 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: HA379096 / To: HA999999	$3,423.32	1
2M110	LR133113	MODULATOR - ABS	LR133113 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP76 / ABS / From: LA567000 / To: LA599999	$2,749.14	1
2M110	LR128886	MODULATOR - ABS	LR128886 MODULATOR - ABS 8HP Gen3 Hybrid Trans / ABS / From: KA554778 / To: MA454793	$2,561.85	1
2M110	LR140560	MODULATOR - ABS	LR140560 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: KA566978 / To: KA569977	$2,297.23	1
2M110	LR143166	MODULATOR - ABS	LR143166 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: JA418596 / To: JA999999	$2,892.83	1
2M110	LR133113	MODULATOR - ABS	LR133113 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP76 / ABS / From: LA400000 / To: LA407180	$2,749.14	1
2M110	LR143019	MODULATOR - ABS	LR143019 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 HEV 4WD / ABS / From: LA407181 / To: LA566999	$2,415.84	1
2M110	LR149365	MODULATOR - ABS	LR149365 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: MA000001 / To: MA448790	$3,054.97	1
2M110	LR154220	MODULATOR - ABS	LR154220 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP70 4WD / ABS / From: KA569978 / To: KA999999	$2,792.63	1
2M110	LR159944	MODULATOR - ABS	LR159944 MODULATOR - ABS 8 Speed Auto Trans ZF 8HP45 / ABS / From: MA448791	$2,751.06	1
2M110	LR159939	MODULATOR - ABS	LR159939 MODULATOR - ABS 8HP Gen3 Hybrid Trans / ABS / From: MA454794	$3,114.29	1

Anti-Lock Braking System (Abs Modulator)

Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol]

Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol] - Anti-Lock Braking System (ABS Modulator)
