Air Conditioning Condensr/Compressr (Front) (3.0L 24V Dohc V6 Tc Diesel, 3.0L 24V V6 Turbo Diesel...

Land Rover Range Rover (2012-2021) [2.0 Turbo Petrol AJ200P]

Find Your Part

Land Rover Range Rover (2012-2021) [2.0 Turbo Petrol AJ200P] - Air Conditioning Condensr/Compressr (Front) (3.0L 24V DOHC V6 TC Diesel, 3.0L 24V V6 Turbo Diesel...

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR005074 BOLT $1.15 To Order
Photo Part No Description Price (each) Stock
RYG500290 BOLT - HEX.HEAD $0.52 IN STOCK
Photo Part No Description Price (each) Stock
LR035462 CLIP - HOSE $3.33 To Order
Photo Part No Description Price (each) Stock
FN106046 NUT - HEX. $1.46 IN STOCK
Photo Part No Description Price (each) Stock
LR044466 O-RING $4.33 To Order
Photo Part No Description Price (each) Stock
LR054871 O-RING $3.30 To Order
Photo Part No Description Price (each) Stock
LR054870 O-RING $3.53 To Order
Photo Part No Description Price (each) Stock
FS106166 SCREW $1.23 IN STOCK
Photo Part No Description Price (each) Stock
LR018707 SCREW $1.05 To Order
Photo Part No Description Price (each) Stock
RYG500160 SCREW $0.62 To Order
Photo Part No Description Price (each) Stock
LR035791 CONDENSER $435.41 To Order
LR110621 CONDENSER $664.50 To Order
LR133116 CONDENSER $704.14 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR086045 KIT - VALVE REPAIR $175.60 To Order
LR086045 KIT - VALVE REPAIR $175.60 To Order
Photo Part No Description Price (each) Stock
LR034502 BRACKET - RADIATOR $11.63 To Order
LR062331 BRACKET - RADIATOR $17.97 To Order
Photo Part No Description Price (each) Stock
LR086926 SENSOR - REFRIGERANT PRESSURE $239.22 To Order
Photo Part No Description Price (each) Stock
LR035490 HOSE - AIR CONDITIONING $195.01 To Order
LR046251 HOSE - AIR CONDITIONING $177.25 To Order
LR061561 HOSE - AIR CONDITIONING $221.13 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR035760 COMPRESSOR - AIR CONDITIONING $1,891.34 To Order
LR057691 COMPRESSOR - AIR CONDITIONING $2,017.95 To Order
LR068127 COMPRESSOR - AIR CONDITIONING $1,392.52 To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR013376 BRACKET - COMPRESSOR $140.38 IN STOCK
Photo Part No Description Price (each) Stock
LR035481 TUBE - COMPRESSOR DELIVERY $228.27 To Order
LR051517 TUBE - COMPRESSOR DELIVERY $174.49 To Order
LR061569 TUBE - COMPRESSOR DELIVERY $168.58 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR035482 TUBE - COMPRESSOR LINE $188.78 To Order
LR061564 TUBE - COMPRESSOR LINE $221.45 To Order
LR072183 TUBE - COMPRESSOR LINE $232.52 To Order
View All
Air Conditioning Condensr/Compressr (Front) (3.0L 24V DOHC V6 TC Diesel, 3.0L 24V V6 Turbo Diesel Std Flow) of Land Rover Land Rover Range Rover (2012-2021) [2.0 Turbo Petrol AJ200P] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HB1 LR005074
BOLT
HEX Flange, Hexagonal Head, M8 X 96.5 		$1.15 3
HB2 RYG500290
BOLT - HEX.HEAD
HEX Flange, Hexagonal Head, M8 x 30MM
IN STOCK 		$0.52 2
HC1 LR035462
CLIP - HOSE
For Air Conditioning Hose 		$3.33 1
HN1 FN106046
NUT - HEX.
Hexagonal Head, M6
IN STOCK 		$1.46 7
HR1 LR044466
O-RING
7.65 X 1.78 		$4.33 4
HR2 LR054871
O-RING
10.82MM X 1.78MM 		$3.30 4
HR3 LR054870
O-RING
16.5 X 1.78MM 		$3.53 4
HS1 FS106166
SCREW
Hexagonal Head, M6 X 16MM
IN STOCK 		$1.23 1
HS2 LR018707
SCREW
6X20, Hexagonal Head 		$1.05 2
HS3 RYG500160
SCREW
Hexagonal Head, M6 X 14MM 		$0.62 1
3L504 LR086045
KIT - VALVE REPAIR
Includes A/C Compressor Control Valve And Snap Ring / To: GA272331 		$175.60 1
3L504 LR086045
KIT - VALVE REPAIR
Includes A/C Compressor Control Valve And Snap Ring / From: GA272332 / To: GA274505 		$175.60 1
8A291 LR034502
BRACKET - RADIATOR
Air Conditioning Condenser / To: EA999999 		$11.63 2
8A291 LR062331
BRACKET - RADIATOR
Air Conditioning Condenser / From: FA000001 		$17.97 2
12A644 LR086926
SENSOR - REFRIGERANT PRESSURE
Refrigerant Pressure Sensor 		$239.22 1
18B402 LR035490
HOSE - AIR CONDITIONING
Condenser Outlet / To: DA109667 		$195.01 1
18B402 LR046251
HOSE - AIR CONDITIONING
Condenser Outlet / From: DA109668 / To: EA155993 		$177.25 1
18B402 LR061561
HOSE - AIR CONDITIONING
Condenser Outlet / From: EA155994 / To: EA194098 		$221.13 1
18B402 LR068878
HOSE - AIR CONDITIONING
Condenser Outlet / From: EA194099 / To: HA999999 		$221.13 1
19D623 LR035760
COMPRESSOR - AIR CONDITIONING
To: EA143173 		$1,891.34 1
19D623 LR057691
COMPRESSOR - AIR CONDITIONING
From: EA143174 / To: EA999999 		$2,017.95 1
19D623 LR068127
COMPRESSOR - AIR CONDITIONING
From: FA000001 / To: GA273528 		$1,392.52 1
19D623 LR086044
COMPRESSOR - AIR CONDITIONING
From: GA273529 / To: GA274505 		$1,398.68 1
19D623 LR112584
COMPRESSOR - AIR CONDITIONING
From: GA274506 		$1,716.27 1
19D624 LR013376
BRACKET - COMPRESSOR
Air Conditioning Compressor Bracket
IN STOCK 		$140.38 1
19N651A LR035481
TUBE - COMPRESSOR DELIVERY
Compressor Inlet / To: EA134626 		$228.27 1
19N651A LR051517
TUBE - COMPRESSOR DELIVERY
Compressor Inlet / From: EA134627 / To: EA163933 		$174.49 1
19N651A LR061569
TUBE - COMPRESSOR DELIVERY
Compressor Inlet / From: EA163934 / To: EA194020 		$168.58 1
19N651A LR072185
TUBE - COMPRESSOR DELIVERY
Compressor Inlet / From: EA194021 		$181.90 1
19N651B LR035482
TUBE - COMPRESSOR LINE
Condenser Inlet Tube / To: EA163933 		$188.78 1
19N651B LR061564
TUBE - COMPRESSOR LINE
Condenser Inlet Tube / From: EA163934 / To: EA194020 		$221.45 1
19N651B LR072183
TUBE - COMPRESSOR LINE
Condenser Inlet Tube / From: EA194021 		$232.52 1
19712 LR035791
CONDENSER
To: KA547796 		$435.41 1
19712 LR110621
CONDENSER
From: KA547797 / To: KA564990 		$664.50 1
19712 LR133116
CONDENSER
From: KA564991 / To: LA589181 		$704.14 1
19712 LR137975
CONDENSER
From: LA589182 		$431.85 1
