Air Conditioning Condensr/Compressr (Front) (4.4L Dohc Ditc V8 Diesel)

Land Rover Range Rover (2012-2021) [2.0 Turbo Petrol AJ200P]

Find Your Part

Land Rover Range Rover (2012-2021) [2.0 Turbo Petrol AJ200P] - Air Conditioning Condensr/Compressr (Front) (4.4L DOHC DITC V8 Diesel)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR005074 BOLT $1.15 To Order
Photo Part No Description Price (each) Stock
FB110156 BOLT - HEX.HEAD $2.68 IN STOCK
Photo Part No Description Price (each) Stock
FB110106 BOLT $1.69 IN STOCK
Photo Part No Description Price (each) Stock
LR035462 CLIP - HOSE $3.33 To Order
Photo Part No Description Price (each) Stock
FN106046 NUT - HEX. $1.46 IN STOCK
Photo Part No Description Price (each) Stock
LR044466 O-RING $4.33 To Order
Photo Part No Description Price (each) Stock
LR054871 O-RING $3.30 To Order
Photo Part No Description Price (each) Stock
LR054870 O-RING $3.53 To Order
Photo Part No Description Price (each) Stock
FS106166 SCREW $1.23 IN STOCK
Photo Part No Description Price (each) Stock
LR018707 SCREW $1.05 To Order
Photo Part No Description Price (each) Stock
LR110621 CONDENSER $664.50 To Order
LR133116 CONDENSER $704.14 To Order
LR035791 CONDENSER $435.41 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR086045 KIT - VALVE REPAIR $175.60 To Order
LR086045 KIT - VALVE REPAIR $175.60 To Order
Photo Part No Description Price (each) Stock
LR034502 BRACKET - RADIATOR $11.63 To Order
LR062331 BRACKET - RADIATOR $17.97 To Order
Photo Part No Description Price (each) Stock
LR086926 SENSOR - REFRIGERANT PRESSURE $239.22 To Order
Photo Part No Description Price (each) Stock
LR035490 HOSE - AIR CONDITIONING $195.01 To Order
LR046251 HOSE - AIR CONDITIONING $177.25 To Order
LR061561 HOSE - AIR CONDITIONING $221.13 To Order
...and 3 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR035761 COMPRESSOR - AIR CONDITIONING $1,754.73 To Order
LR057692 COMPRESSOR - AIR CONDITIONING $1,638.39 To Order
LR068128 COMPRESSOR - AIR CONDITIONING $1,187.58 To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR079507 BRACKET - COMPRESSOR $37.65 To Order
LR079507 BRACKET - COMPRESSOR $37.65 To Order
Photo Part No Description Price (each) Stock
LR072186 TUBE - COMPRESSOR DELIVERY $217.13 To Order
LR061571 TUBE - COMPRESSOR DELIVERY $221.45 To Order
LR072186 TUBE - COMPRESSOR DELIVERY $217.13 To Order
Photo Part No Description Price (each) Stock
LR035484 TUBE - COMPRESSOR LINE $155.51 To Order
LR061566 TUBE - COMPRESSOR LINE $221.45 To Order
LR072571 TUBE - COMPRESSOR LINE $243.25 To Order
View All
Air Conditioning Condensr/Compressr (Front) (4.4L DOHC DITC V8 Diesel) of Land Rover Land Rover Range Rover (2012-2021) [2.0 Turbo Petrol AJ200P] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HB1 LR005074
BOLT
HEX Flange, Hexagonal Head, M8 X 96.5 		$1.15 3
HB2 FB110156
BOLT - HEX.HEAD
HEX Flange, Hexagonal Head, M10 x 75MM
IN STOCK 		$2.68 1
HB3 FB110106
BOLT
Hexagonal Head, M10 X 50MM
IN STOCK 		$1.69 1
HC1 LR035462
CLIP - HOSE
For Air Conditioning Hose 		$3.33 1
HN1 FN106046
NUT - HEX.
Hexagonal Head, M6
IN STOCK 		$1.46 8
HR1 LR044466
O-RING
7.65 X 1.78 		$4.33 4
HR2 LR054871
O-RING
10.82MM X 1.78MM 		$3.30 4
HR3 LR054870
O-RING
16.5 X 1.78MM 		$3.53 4
HS1 FS106166
SCREW
Hexagonal Head, M6 X 16MM
IN STOCK 		$1.23 1
HS2 LR018707
SCREW
6X20, Hexagonal Head 		$1.05 2
3L504 LR086045
KIT - VALVE REPAIR
Includes A/C Compressor Control Valve And Snap Ring / To: GA272331 		$175.60 1
3L504 LR086045
KIT - VALVE REPAIR
Includes A/C Compressor Control Valve And Snap Ring / From: GA272332 / To: GA274942 		$175.60 1
8A291 LR034502
BRACKET - RADIATOR
Air Conditioning Condenser / To: EA999999 		$11.63 2
8A291 LR062331
BRACKET - RADIATOR
Air Conditioning Condenser / From: FA000001 		$17.97 2
12A644 LR086926
SENSOR - REFRIGERANT PRESSURE
Refrigerant Pressure Sensor 		$239.22 1
18B402 LR035490
HOSE - AIR CONDITIONING
Condenser Outlet / To: DA109667 		$195.01 1
18B402 LR046251
HOSE - AIR CONDITIONING
Condenser Outlet / From: DA109668 / To: EA155993 		$177.25 1
18B402 LR061561
HOSE - AIR CONDITIONING
Condenser Outlet / From: EA155994 / To: EA194098 		$221.13 1
18B402 LR068878
HOSE - AIR CONDITIONING
Condenser Outlet / From: EA194099 / To: HA999999 		$221.13 1
18B402 LR082205
HOSE - AIR CONDITIONING
Condenser Outlet / From: JA000001 / To: LA590569 		$201.17 1
18B402 LR135856
HOSE - AIR CONDITIONING
Condenser Outlet / From: LA590570 		$201.17 1
19D623 LR035761
COMPRESSOR - AIR CONDITIONING
To: EA143193 		$1,754.73 1
19D623 LR057692
COMPRESSOR - AIR CONDITIONING
From: EA143194 / To: FA204832 		$1,638.39 1
19D623 LR068128
COMPRESSOR - AIR CONDITIONING
From: FA204833 / To: GA273528 		$1,187.58 1
19D623 LR112585
COMPRESSOR - AIR CONDITIONING
From: GA274943 		$1,470.27 1
19D623 LR086043
COMPRESSOR - AIR CONDITIONING
From: GA273529 / To: GA274942 		$1,475.59 1
19N586 LR079507
BRACKET - COMPRESSOR
Air Conditioning Compressor Bracket / To: FA999999 		$37.65 1
19N586 LR079507
BRACKET - COMPRESSOR
Air Conditioning Compressor Bracket / From: GA000001 		$37.65 1
19N651A LR072186
TUBE - COMPRESSOR DELIVERY
Compressor Inlet / To: EA163933 		$217.13 1
19N651A LR061571
TUBE - COMPRESSOR DELIVERY
Compressor Inlet / From: EA163934 / To: EA194020 		$221.45 1
19N651A LR072186
TUBE - COMPRESSOR DELIVERY
Compressor Inlet / From: EA194021 		$217.13 1
19N651B LR035484
TUBE - COMPRESSOR LINE
Condenser Inlet Tube / To: EA163933 		$155.51 1
19N651B LR061566
TUBE - COMPRESSOR LINE
Condenser Inlet Tube / From: EA163934 / To: EA194020 		$221.45 1
19N651B LR072571
TUBE - COMPRESSOR LINE
Condenser Inlet Tube / From: EA194021 		$243.25 1
19712 LR110621
CONDENSER
From: KA547797 / To: KA564990 		$664.50 1
19712 LR133116
CONDENSER
From: KA564991 / To: LA589181 		$704.14 1
19712 LR035791
CONDENSER
To: KA547796 		$435.41 1
19712 LR137975
CONDENSER
From: LA589182 		$431.85 1
