Name: Front Seat Pads/Valances & Heating (Heating)
Rating: 4.0 (1 reviews)

Front Seat Pads/Valances & Heating (Heating) of Land Rover Land Rover Range Rover (2022+) [4.4 V8 Turbo Petrol NC10]

View All

Land Rover Range Rover (2022+) [4.4 V8 Turbo Petrol NC10] - Front Seat Pads/Valances & Heating (Heating)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR166723	SLIP MAT - SENSOR	$100.31	To Order

Photo	Part No	Description	Price (each)	Stock
	LR041100	RETAINER - SEAT DUCT	$6.53	To Order

Photo	Part No	Description	Price (each)	Stock
	LR137967	SENSOR - BODY WEIGHT - AIRBAG	$97.83	To Order

Photo	Part No	Description	Price (each)	Stock
	LR087680	SENSOR - SEAT POSITION	$72.79	To Order

Photo	Part No	Description	Price (each)	Stock
	LR119588	HOUSING - SENSOR	$49.98	To Order

Photo	Part No	Description	Price (each)	Stock
	LR151859	ELEMENT - FRONT SEAT CUSHION HEATING	$161.02	To Order
	LR151860	ELEMENT - FRONT SEAT CUSHION HEATING	$161.02	To Order
	LR171351	ELEMENT - HEATING	$160.54	To Order

Photo	Part No	Description	Price (each)	Stock
	LR151712	ELEMENT - FRONT SEAT BACK HEATING	$161.02	To Order
	LR151714	ELEMENT - FRONT SEAT BACK HEATING	$161.02	To Order
	LR171320	ELEMENT - FRONT SEAT BACK HEATING	$160.54	To Order

Photo	Part No	Description	Price (each)	Stock
	LR154050	SQUAB FOAM	$120.51	To Order
	LR154050	SQUAB FOAM	$120.51	To Order

Photo	Part No	Description	Price (each)	Stock
	LR154051	SQUAB FOAM	$120.51	To Order
	LR154051	SQUAB FOAM	$120.51	To Order

Photo	Part No	Description	Price (each)	Stock
	LR150388	AIR DIFFUSER PAD - SEAT	$75.54	To Order
	LR150389	AIR DIFFUSER PAD - SEAT	$87.36	To Order

Photo	Part No	Description	Price (each)	Stock
	LR150393	AIR DIFFUSER PAD - SEAT	$87.36	To Order
	LR155072	AIR DIFFUSER PAD - SEAT	$87.36	To Order

Photo	Part No	Description	Price (each)	Stock
	LR150352	DUCT - SEAT - AIR	$319.24	To Order

Photo	Part No	Description	Price (each)	Stock
	LR150354	DUCT - SEAT - AIR	$339.35	To Order
	LR152861	DUCT - SEAT - AIR	$338.35	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
<18C580A	LR150352	DUCT - SEAT - AIR	LR150352 DUCT - SEAT - AIR Heated and Vented Front Seats, Heated and Ventilated Rear Seats / For Seat Cushion, RH/LH	$319.24	2
<18C580B	LR150354	DUCT - SEAT - AIR	LR150354 DUCT - SEAT - AIR With Heated/Cooled Front Seats Only / RH, For Seat Cushion	$339.35	1
<18C580B	LR152861	DUCT - SEAT - AIR	LR152861 DUCT - SEAT - AIR With Heated/Cooled Front Seats Only / LH, For Seat Cushion	$338.35	1
<18C580C	LR150347	DUCT - SEAT - AIR	LR150347 DUCT - SEAT - AIR Heated and Vented Front Seats, Heated and Ventilated Rear Seats / For Seat Back, RH/LH	$319.24	2
<18C580D	LR150349	DUCT - SEAT - AIR	LR150349 DUCT - SEAT - AIR With Heated/Cooled Front Seats Only / For Seat Back, RH/LH	$339.35	2
<017B84A	LR154050	SQUAB FOAM	LR154050 SQUAB FOAM Less SV Model Spec, Semi Aniline Leather Perf / For Seat Back, Lower, RH/LH	$120.51	2
<017B84A	LR154050	SQUAB FOAM	LR154050 SQUAB FOAM SV1 Model Spec / For Seat Back, Lower, RH/LH / From: PA000001	$120.51	2
<017B84B	LR154051	SQUAB FOAM	LR154051 SQUAB FOAM Less SV Model Spec, Windsor Leather Perforated / For Seat Back, RH/LH, Upper	$120.51	2
<017B84B	LR154051	SQUAB FOAM	LR154051 SQUAB FOAM SV1 Model Spec / For Seat Back, RH/LH, Upper / From: PA000001	$120.51	2
<018W18A	LR150388	AIR DIFFUSER PAD - SEAT	LR150388 AIR DIFFUSER PAD - SEAT Heated and Vented Front Seats / For Seat Cushion, RH/LH	$75.54	2
<018W18A	LR150389	AIR DIFFUSER PAD - SEAT	LR150389 AIR DIFFUSER PAD - SEAT With Heated/Cooled Front Seats Only / For Seat Cushion, RH/LH	$87.36	2
<018W18B	LR150393	AIR DIFFUSER PAD - SEAT	LR150393 AIR DIFFUSER PAD - SEAT With Heated/Cooled Front Seats Only / For Seat Back, RH/LH	$87.36	2
<018W18B	LR155072	AIR DIFFUSER PAD - SEAT	LR155072 AIR DIFFUSER PAD - SEAT Heated and Vented Front Seats / For Seat Back, RH/LH	$87.36	2
<441A14	LR119588	HOUSING - SENSOR	LR119588 HOUSING - SENSOR With Head Impact Crash Criteria / For Passenger Front Seat	$49.98	1
<13212	LR166723	SLIP MAT - SENSOR	LR166723 SLIP MAT - SENSOR With Head Impact Crash Criteria / For Passenger Front Seat	$100.31	1
<45645	LR041100	RETAINER - SEAT DUCT	LR041100 RETAINER - SEAT DUCT Premium Seat Frame, With Heated/Cooled Front Seats Only / Air Duct, RH/LH	$6.53	2
12K073	LR137967	SENSOR - BODY WEIGHT - AIRBAG	LR137967 SENSOR - BODY WEIGHT - AIRBAG Sensor-Occ W/out Pass Airbag Cutoff / For Passenger Front Seat, Seat Belt Reminder	$97.83	1
14B004	LR087680	SENSOR - SEAT POSITION	LR087680 SENSOR - SEAT POSITION Sensor - Occupant Classification / Sensor - Seat Track Position	$72.79	1
14D696A	LR151859	ELEMENT - FRONT SEAT CUSHION HEATING	LR151859 ELEMENT - FRONT SEAT CUSHION HEATING Hybrid Seat Frame, Less SV Model Spec / For Seat Cushion, RH/LH	$161.02	2
14D696A	LR151860	ELEMENT - FRONT SEAT CUSHION HEATING	LR151860 ELEMENT - FRONT SEAT CUSHION HEATING Less SV Model Spec, Premium Seat Frame / For Seat Cushion, RH/LH	$161.02	2
14D696A	LR171351	ELEMENT - HEATING	LR171351 ELEMENT - HEATING SV1 Model Spec / For Seat Cushion, RH/LH / From: PA000001	$160.54	2
14D696B	LR151712	ELEMENT - FRONT SEAT BACK HEATING	LR151712 ELEMENT - FRONT SEAT BACK HEATING Hybrid Seat Frame, Less SV Model Spec / For Seat Back, RH/LH	$161.02	2
14D696B	LR151714	ELEMENT - FRONT SEAT BACK HEATING	LR151714 ELEMENT - FRONT SEAT BACK HEATING Less SV Model Spec, Premium Seat Frame / For Seat Back, RH/LH	$161.02	2
14D696B	LR171320	ELEMENT - FRONT SEAT BACK HEATING	LR171320 ELEMENT - FRONT SEAT BACK HEATING SV1 Model Spec / For Seat Back, RH/LH / From: PA000001	$160.54	2

Front Seat Pads/Valances & Heating (Heating)

Land Rover Range Rover (2022+) [4.4 V8 Turbo Petrol NC10]

Land Rover Range Rover (2022+) [4.4 V8 Turbo Petrol NC10] - Front Seat Pads/Valances & Heating (Heating)
