View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR033002	BOLT AND WASHER - TORX HEAD	$1.51	To Order

Photo	Part No	Description	Price (each)	Stock
	LR092412	TUBE - OUTLET	$124.67	To Order

Photo	Part No	Description	Price (each)	Stock
	LR138643	TUBE - OUTLET	$80.53	To Order

Photo	Part No	Description	Price (each)	Stock
	LR093490	ACTUATOR - SUPERCHARGER BYPASS	$281.77	To Order

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	LR033002	BOLT AND WASHER - TORX HEAD	LR033002 BOLT AND WASHER - TORX HEAD M6 X 20.5, To Valve, Torx / From: MA000001	$1.51	3
3D022	LR141942	HOSE - AIR	LR141942 HOSE - AIR From: MA000001 / To: MA315690	$295.27	1
3D022	LR156361	TUBE - OUTLET	LR156361 TUBE - OUTLET From: MA315691	$297.97	1
6F073	LR092412	TUBE - OUTLET	LR092412 TUBE - OUTLET From: MA000001	$124.67	1
6K769	LR138643	TUBE - OUTLET	LR138643 TUBE - OUTLET From: MA000001	$80.53	1
9C854	LR093490	ACTUATOR - SUPERCHARGER BYPASS	LR093490 ACTUATOR - SUPERCHARGER BYPASS From: MA000001	$281.77	1
