Active Anti-Roll Bar System (Rear, Stabilizer Bar) (With Roll Stability Control, With Ace...

Land Rover Range Rover Sport (2010-2013) [5.0 OHC SGDI SC V8 Petrol]

Find Your Part

Land Rover Range Rover Sport (2010-2013) [5.0 OHC SGDI SC V8 Petrol] - Active Anti-Roll Bar System (Rear, Stabilizer Bar) (With Roll Stability Control, With ACE...

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
FT110206 BOLT $2.04 IN STOCK
Photo Part No Description Price (each) Stock
RYG500090 BOLT (NON HAZ) $2.64 To Order
Photo Part No Description Price (each) Stock
FY112056 NUT - HEX. $1.92 IN STOCK
Photo Part No Description Price (each) Stock
RYP500030 SCREW (NON HAZ) $3.50 IN STOCK
Photo Part No Description Price (each) Stock
RVU000022 BUSH (NON HAZ) $37.83 To Order
Photo Part No Description Price (each) Stock
LR018309 BAR - ROLL $2,622.82 To Order
LR020701 BAR - REAR STABILIZER $2,190.81 To Order
LR024073 BAR - ROLL (NON HAZ) $2,692.02 To Order
...and 3 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
RBU000281 CLAMP - RUBBER BUSH $3.97 IN STOCK
Photo Part No Description Price (each) Stock
RGD500140 LINK - STABILIZER BAR $55.68 To Order
View All
Active Anti-Roll Bar System (Rear, Stabilizer Bar) (With Roll Stability Control, With ACE Suspension) ((V) FROMAA000001) of Land Rover Land Rover Range Rover Sport (2010-2013) [5.0 OHC SGDI SC V8 Petrol] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HB1 FT110206
BOLT
HEX Flange, M10 X 20MM / From: AA000001
IN STOCK 		$2.04 4
HB2 RYG500090
BOLT (NON HAZ)
HEX Flange, M12 / From: AA000001 		$2.64 6
HM1 FY112056
NUT - HEX.
Hex Nut Type, M12 / From: AA000001
IN STOCK 		$1.92 4
HS1 RYP500030
SCREW (NON HAZ)
Bleeder Screw / From: AA000001
IN STOCK 		$3.50 2
2C324 RVU000022
BUSH (NON HAZ)
Stabilizer Bar / From: AA000001 		$37.83 2
5A772 LR018309
BAR - ROLL
3.0L 24V DOHC V6 TC Diesel / Includes Insulators And Clamps / From: AA000001 / To: AA229469 		$2,622.82 1
5A772 LR020701
BAR - REAR STABILIZER
3.0L 24V DOHC V6 TC Diesel / Includes Insulators And Clamps / From: AA229470 / To: AA258697 		$2,190.81 1
5A772 LR024073
BAR - ROLL (NON HAZ)
3.0L 24V DOHC V6 TC Diesel / Includes Insulators And Clamps / From: AA258698 		$2,692.02 1
5A772 LR018310
BAR - ROLL
5.0L OHC SGDI SC V8 Petrol - AJ133 / Includes Insulators And Clamps / From: AA000001 / To: AA229469 		$2,177.64 1
5A772 LR020702
BAR ASSY - ROLL
5.0L OHC SGDI SC V8 Petrol - AJ133 / Includes Insulators And Clamps / From: AA229470 / To: AA258697 		$2,115.07 1
5A772 LR024072
BAR - STABILIZER (NON HAZ)
5.0L OHC SGDI SC V8 Petrol - AJ133 / Includes Insulators And Clamps / From: AA258698 		$2,686.63 1
5B484 RBU000281
CLAMP - RUBBER BUSH
Stabilizer Bar / From: AA000001
IN STOCK 		$3.97 2
5C486 RGD500140
LINK - STABILIZER BAR
From: AA000001 		$55.68 2
