Rear Knuckle And Suspension Arms (Rear Knuckle And Hub) ((V) Fromaa000001)

Land Rover Discovery 4 (2010-2016) [5.0 OHC SGDI NA V8 Petrol]

Find Your Part

Land Rover Discovery 4 (2010-2016) [5.0 OHC SGDI NA V8 Petrol] - Rear Knuckle And Suspension Arms (Rear Knuckle And Hub) ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
SYG000013 BOLT $3.53 IN STOCK
Photo Part No Description Price (each) Stock
RYV000010 CIRCLIP $4.29 IN STOCK
Photo Part No Description Price (each) Stock
SKZ500012 CLIP $7.48 To Order
Photo Part No Description Price (each) Stock
RLG000010 CLIP $4.03 To Order
Photo Part No Description Price (each) Stock
RFD500020 NUT - HEX. $8.88 To Order
LR024151 NUT AND WASHER - HEX. $10.20 IN STOCK
Photo Part No Description Price (each) Stock
RUC500120 HUB - WHEEL $1,010.64 To Order
Photo Part No Description Price (each) Stock
RFM500020 BEARING - REAR WHEEL $174.50 To Order
LR021939 KIT - WHEEL BEARING REPAIR $159.64 To Order
LR048084 KIT - WHEEL BEARING REPAIR $151.26 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
RLH500120 KNUCKLE AND HUB $491.34 To Order
RLH500130 KNUCKLE AND HUB $467.97 To Order
LR045824 KNUCKLE - REAR WHEEL $491.34 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
RHF500100 BUSH - REAR SUSPENSION $85.23 To Order
Photo Part No Description Price (each) Stock
RBK500220 BUSH - REAR SUSPENSION $52.19 To Order
LR032644 BUSH - REAR SUSPENSION $69.83 To Order
View All
Rear Knuckle And Suspension Arms (Rear Knuckle And Hub) ((V) FROMAA000001) of Land Rover Land Rover Discovery 4 (2010-2016) [5.0 OHC SGDI NA V8 Petrol] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HB1 SYG000013
BOLT
External Torx Head, Knuckle To Calliper, M12 X 35MM / From: AA000001
IN STOCK 		$3.53 4
HC1 RYV000010
CIRCLIP
Lower Bush Rear Knuckle / From: AA000001
IN STOCK 		$4.29 2
HC2 SKZ500012
CLIP
Drum - Brake / From: AA000001 		$7.48 2
HC3 RLG000010
CLIP
Bearing / From: AA000001 		$4.03 2
HN1 RFD500020
NUT - HEX.
Hex Nut Type, Inspect The Thread Lead Before Ordering, M24 X 1.5MM / From: AA000001 		$8.88 2
HN1 LR024151
NUT AND WASHER - HEX.
Inspect The Thread Lead Before Ordering, M24X2.0 / From: AA000001
IN STOCK 		$10.20 2
5A968 RLH500120
KNUCKLE AND HUB
RH / From: AA000001 / To: BA999999 		$491.34 1
5A968 RLH500130
KNUCKLE AND HUB
LH / From: AA000001 / To: BA999999 		$467.97 1
5A968 LR045824
KNUCKLE - REAR WHEEL
RH / From: CA000001 		$491.34 1
5A968 LR045825
KNUCKLE - REAR WHEEL
LH / From: CA000001 		$491.34 1
5K792A RHF500100
BUSH - REAR SUSPENSION
Upper / From: AA000001 		$85.23 2
5K792B RBK500220
BUSH - REAR SUSPENSION
Lower Bush Rear Knuckle / From: AA000001 / To: CA647160 		$52.19 2
5K792B LR032644
BUSH - REAR SUSPENSION
Lower Bush Rear Knuckle / From: CA647161 		$69.83 2
1104 RUC500120
HUB - WHEEL
From: AA000001 		$1,010.64 2
1225 RFM500020
BEARING - REAR WHEEL
Kit / From: AA000001 / To: AA518798 		$174.50 2
1225 LR021939
KIT - WHEEL BEARING REPAIR
Kit / From: AA518799 / To: DA670000 		$159.64 2
1225 LR048084
KIT - WHEEL BEARING REPAIR
Kit / From: DA670001 / To: EA706372 		$151.26 2
1225 LR045917
KIT - WHEEL BEARING REPAIR
Kit / From: EA706373 		$168.95 2
