Front Susp.arms/Stabilizer/X-Member (Front Upper And Lower Arms) ((V) Fromaa000001)

Land Rover Discovery 4 (2010-2016) [5.0 OHC SGDI NA V8 Petrol]

Find Your Part

Land Rover Discovery 4 (2010-2016) [5.0 OHC SGDI NA V8 Petrol] - Front Susp.Arms/Stabilizer/X-Member (Front Upper And Lower Arms) ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
RYG000420 BOLT $6.78 IN STOCK
Photo Part No Description Price (each) Stock
RDI000034 BOLT $13.74 IN STOCK
Photo Part No Description Price (each) Stock
FY112056 NUT - HEX. $1.95 IN STOCK
Photo Part No Description Price (each) Stock
FY114056 NUT - HEX. $1.25 IN STOCK
Photo Part No Description Price (each) Stock
FX116056 NUT - FLANGED $6.16 IN STOCK
LR079261 NUT $4.08 IN STOCK
Photo Part No Description Price (each) Stock
RYG000440 BOLT $17.25 IN STOCK
Photo Part No Description Price (each) Stock
RYF000203 WASHER $8.61 IN STOCK
Photo Part No Description Price (each) Stock
RBK500170 JOINT - BALL $73.22 To Order
Photo Part No Description Price (each) Stock
RBK500280 JOINT - BALL $73.22 To Order
Photo Part No Description Price (each) Stock
RBX500311 BUSH - FRONT SUSPENSION ARM $101.32 To Order
LR051585 BUSH - FRONT SUSPENSION ARM $101.32 To Order
Photo Part No Description Price (each) Stock
LR014132 ARM - FRONT SUSPENSION $418.61 To Order
LR014133 ARM - FRONT SUSPENSION $418.61 To Order
LR051614 ARM - FRONT SUSPENSION $432.15 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR014136 ARM - FRONT SUSPENSION $350.86 To Order
LR014138 ARM - FRONT SUSPENSION $396.23 To Order
LR014139 ARM - FRONT SUSPENSION $396.23 To Order
...and 19 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
RBX500291 BUSH - FRONT SUSPENSION ARM $52.97 To Order
LR025159 BUSH - SUSPENSION ARM $100.91 To Order
LR051586 BUSH - SUSPENSION ARM $107.37 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
RBX500301 BUSH $18.92 To Order
LR056964 BUSH - SUSPENSION ARM $81.19 To Order
View All
Front Susp.Arms/Stabilizer/X-Member (Front Upper And Lower Arms) ((V) FROMAA000001) of Land Rover Land Rover Discovery 4 (2010-2016) [5.0 OHC SGDI NA V8 Petrol] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HB1 RYG000420
BOLT
M14 X 80MM / From: AA000001
IN STOCK 		$6.78 4
HB2 RDI000034
BOLT
M16 X 120MM / From: AA000001
IN STOCK 		$13.74 4
HM1 FY112056
NUT - HEX.
Hex Nut Type, M12 / From: AA000001
IN STOCK 		$1.95 2
HN1 FY114056
NUT - HEX.
Hexagonal Head, M14 / From: AA000001
IN STOCK 		$1.25 4
HN2 FX116056
NUT - FLANGED
M16 / From: AA000001 / To: BA555713
IN STOCK 		$6.16 4
HN2 LR079261
NUT
M16 / From: BA555714
IN STOCK 		$4.08 4
HS1 RYG000440
BOLT
M16 X 200MM, Shock Absorber To The Lower Arm / From: AA000001
IN STOCK 		$17.25 2
HW1 RYF000203
WASHER
Adjusting / From: AA000001
IN STOCK 		$8.61 4
3A052A LR014132
ARM - FRONT SUSPENSION
RH, Complete Assembly, Upper / From: AA000001 / To: EA719754 		$418.61 1
3A052A LR014133
ARM - FRONT SUSPENSION
LH, Complete Assembly, Upper / From: AA000001 / To: EA719754 		$418.61 1
3A052A LR051614
ARM - FRONT SUSPENSION
RH, Complete Assembly, Upper / From: EA719755 		$432.15 1
3A052A LR051615
ARM - FRONT SUSPENSION
LH, Complete Assembly, Upper / From: EA719755 		$414.88 1
3A052B LR014136
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / RH, Complete Assembly, Lower / From: AA000001 / To: AA551483 		$350.86 1
3A052B LR014138
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / LH, Complete Assembly, Lower / From: AA000001 / To: AA551483 		$396.23 1
3A052B LR014139
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / LH, Complete Assembly, Lower / From: AA000001 / To: AA551483 		$396.23 1
3A052B LR014137
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / RH, Complete Assembly, Lower / From: AA000001 / To: AA551483 		$384.34 1
3A052B LR025610
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / RH, Complete Assembly, Lower / From: AA551484 / To: EA153861 		$480.80 1
3A052B LR025611
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / RH, Complete Assembly, Lower / From: AA551484 / To: EA153861 		$410.64 1
3A052B LR025613
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / LH, Complete Assembly, Lower / From: AA551484 / To: EA153861 		$532.40 1
3A052B LR025616
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / LH, Complete Assembly, Lower / From: AA551484 / To: EA153861 		$420.80 1
3A052B LR051583
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / RH, Complete Assembly, Lower / From: EA153862 / To: EA184497 		$538.81 1
3A052B LR051612
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / RH, Complete Assembly, Lower / From: EA153862 / To: EA184497 		$506.79 1
3A052B LR073367
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / RH, Complete Assembly, Lower / From: EA184498 / To: GA816748
IN STOCK 		$215.54 1
3A052B LR071931
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / RH, Complete Assembly, Lower / From: EA184498 / To: GA816991 		$503.82 1
3A052B LR051584
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / LH, Complete Assembly, Lower / From: EA153862 / To: EA184497 		$546.32 1
3A052B LR051613
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / LH, Complete Assembly, Lower / From: EA153862 / To: EA184497 		$569.20 1
3A052B LR073369
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / LH, Complete Assembly, Lower / From: EA184498 / To: GA816748
IN STOCK 		$224.18 1
3A052B LR072040
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / LH, Complete Assembly, Lower / From: EA184498 / To: GA816991 		$528.96 1
3A052B LR073367
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / RH, Complete Assembly, Lower / From: GA816749 / To: GA818749
IN STOCK 		$215.54 1
3A052B LR073369
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / LH, Complete Assembly, Lower / From: GA816749 / To: GA818749
IN STOCK 		$224.18 1
3A052B LR073370
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / LH, Complete Assembly, Lower / From: GA816992
IN STOCK 		$260.36 1
3A052B LR073368
ARM - FRONT SUSPENSION
With Standard Duty Coil Spring Susp / RH, Complete Assembly, Lower / From: GA816992
IN STOCK 		$247.19 1
3A052B LR138431
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / RH, Complete Assembly, Lower / From: GA818750 		$390.94 1
3A052B LR138432
ARM - FRONT SUSPENSION
With Four Corner Air Suspension / LH, Complete Assembly, Lower / From: GA818750 		$408.57 1
3C377 RBX500311
BUSH - FRONT SUSPENSION ARM
Front, Lower / From: AA000001 / To: AA999999 		$101.32 2
3C377 LR051585
BUSH - FRONT SUSPENSION ARM
Front, Lower / From: BA000001 		$101.32 1
5K486A RBX500291
BUSH - FRONT SUSPENSION ARM
Hydrabush, Lower, Rear / From: AA000001 / To: AA551483 		$52.97 2
5K486A LR025159
BUSH - SUSPENSION ARM
Hydrabush, Lower, Rear / From: AA551484 / To: FA759920 		$100.91 2
5K486A LR051586
BUSH - SUSPENSION ARM
Hydrabush, Lower, Rear / From: FA759921 / To: GA816748 		$107.37 2
5K486A LR073366
BUSH - FRONT SUSPENSION ARM
Hydrabush, Lower, Rear / From: GA816749 		$60.88 2
5K486B RBX500301
BUSH
Front / Rear, Upper / From: AA000001 / To: BA999999 		$18.92 4
5K486B LR056964
BUSH - SUSPENSION ARM
Front / Rear, Upper / From: CA000001 		$81.19 4
3050A RBK500170
JOINT - BALL
Includes Circlip, Service Kit / From: AA000001 		$73.22 2
3050B RBK500280
JOINT - BALL
35MM Joint Assy - Ball, Includes Circlip, Service Kit / From: AA000001 		$73.22 2
