Air Conditioning Condensr/Compressr (Front) (3.0L Aj20P6 Petrol High, 3.0L Aj20D6 Diesel High) ((V)...

Land Rover Range Rover (2012-2021) [3.0 I6 Turbo Diesel AJ20D6]

Find Your Part

Land Rover Range Rover (2012-2021) [3.0 I6 Turbo Diesel AJ20D6] - Air Conditioning Condensr/Compressr (Front) (3.0L AJ20P6 Petrol High, 3.0L AJ20D6 Diesel High) ((V)...

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR005074 BOLT $1.15 To Order
Photo Part No Description Price (each) Stock
FB108076 BOLT $0.62 To Order
Photo Part No Description Price (each) Stock
LR035462 CLIP - HOSE $3.32 To Order
Photo Part No Description Price (each) Stock
FN106046 NUT - HEX. $1.46 IN STOCK
Photo Part No Description Price (each) Stock
LR044466 O-RING $4.31 To Order
Photo Part No Description Price (each) Stock
LR054871 O-RING $3.30 To Order
Photo Part No Description Price (each) Stock
LR054870 O-RING $3.52 To Order
Photo Part No Description Price (each) Stock
FS106166 SCREW $1.23 IN STOCK
Photo Part No Description Price (each) Stock
LR018707 SCREW $1.05 To Order
Photo Part No Description Price (each) Stock
RYG500160 SCREW $0.62 To Order
Photo Part No Description Price (each) Stock
LR133116 CONDENSER $702.15 To Order
LR181384 CONDENSER $415.38 IN STOCK
LR137975 CONDENSER $430.63 To Order
Photo Part No Description Price (each) Stock
LR062331 BRACKET - RADIATOR $17.92 To Order
Photo Part No Description Price (each) Stock
LR063161 BRACKET - INTERCOOLER RADIATOR $6.41 To Order
Photo Part No Description Price (each) Stock
LR063162 BRACKET - INTERCOOLER RADIATOR $6.41 To Order
Photo Part No Description Price (each) Stock
LR063164 BRACKET - INTERCOOLER RADIATOR $6.17 To Order
Photo Part No Description Price (each) Stock
LR063165 BRACKET - INTERCOOLER RADIATOR $6.50 To Order
Photo Part No Description Price (each) Stock
LR086926 SENSOR - REFRIGERANT PRESSURE $238.54 To Order
Photo Part No Description Price (each) Stock
LR082205 HOSE - AIR CONDITIONING $200.60 To Order
LR135856 HOSE - AIR CONDITIONING $200.60 To Order
Photo Part No Description Price (each) Stock
LR112585 COMPRESSOR - AIR CONDITIONING $1,466.11 To Order
Photo Part No Description Price (each) Stock
LR123056 BRACKET - COMPRESSOR $58.38 To Order
Photo Part No Description Price (each) Stock
LR120445 TUBE - A/C COMPRESSOR $186.91 To Order
Photo Part No Description Price (each) Stock
LR120446 TUBE - COMPRESSOR LINE $184.33 To Order
View All
Air Conditioning Condensr/Compressr (Front) (3.0L AJ20P6 Petrol High, 3.0L AJ20D6 Diesel High) ((V) FROMKA000001) of Land Rover Land Rover Range Rover (2012-2021) [3.0 I6 Turbo Diesel AJ20D6] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HB1 LR005074
BOLT
Hexagonal Head, M8 X 96.5 / From: KA000001 		$1.15 3
HB2 FB108076
BOLT
M8 X 35MM / From: KA000001 		$0.62 4
HC1 LR035462
CLIP - HOSE
For Air Conditioning Hose / From: KA000001 		$3.32 1
HN1 FN106046
NUT - HEX.
Hexagonal Head, M6 / From: KA000001
IN STOCK 		$1.46 6
HR1 LR044466
O-RING
7.65 X 1.78 / From: KA000001 		$4.31 4
HR2 LR054871
O-RING
10.82MM X 1.78MM / From: KA000001 		$3.30 4
HR3 LR054870
O-RING
16.5 X 1.78MM / From: KA000001 		$3.52 4
HS1 FS106166
SCREW
Hexagonal Head, M6 X 16MM / From: KA000001
IN STOCK 		$1.23 2
HS2 LR018707
SCREW
6X20, Hexagonal Head / From: KA000001 		$1.05 2
HS3 RYG500160
SCREW
Hexagonal Head, M6 X 14MM / From: KA000001 		$0.62 1
8A291 LR062331
BRACKET - RADIATOR
Air Conditioning Condenser / From: KA000001 		$17.92 2
12A644 LR086926
SENSOR - REFRIGERANT PRESSURE
Refrigerant Pressure Sensor / From: KA000001 		$238.54 1
18B402 LR082205
HOSE - AIR CONDITIONING
Condenser Outlet / From: KA000001 / To: LA590569 		$200.60 1
18B402 LR135856
HOSE - AIR CONDITIONING
Condenser Outlet / From: LA590570 		$200.60 1
19D623 LR112585
COMPRESSOR - AIR CONDITIONING
From: KA000001 		$1,466.11 1
19D624 LR123056
BRACKET - COMPRESSOR
Air Conditioning Compressor Bracket / From: KA000001 		$58.38 1
19N651A LR120445
TUBE - A/C COMPRESSOR
Compressor Inlet / From: KA000001 		$186.91 1
19N651B LR120446
TUBE - COMPRESSOR LINE
Condenser Inlet Tube / From: KA000001 		$184.33 1
12257A LR063161
BRACKET - INTERCOOLER RADIATOR
3.0L AJ20D6 Diesel High / RH Upper / From: LA000001 		$6.41 1
12257B LR063162
BRACKET - INTERCOOLER RADIATOR
3.0L AJ20D6 Diesel High / LH Upper / From: LA000001 		$6.41 1
12257C LR063164
BRACKET - INTERCOOLER RADIATOR
3.0L AJ20D6 Diesel High / LH Lower / From: LA000001 		$6.17 1
12257D LR063165
BRACKET - INTERCOOLER RADIATOR
3.0L AJ20D6 Diesel High / RH Lower / From: LA000001 		$6.50 1
19712 LR133116
CONDENSER
3.0L AJ20P6 Petrol High / From: KA000001 / To: LA589181 		$702.15 1
19712 LR181384
CONDENSER
3.0L AJ20D6 Diesel High / From: LA000001
IN STOCK 		$415.38 1
19712 LR137975
CONDENSER
3.0L AJ20P6 Petrol High / From: LA589182 		$430.63 1
