Rear Springs And Shock Absorbers ((V) Fromaa000001)

Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC]

Find Your Part

Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC] - Rear Springs And Shock Absorbers ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR014904 CLIP - WIRING ( NON HAZ) $2.40 To Order
Photo Part No Description Price (each) Stock
LR015001 CLIP $1.11 To Order
Photo Part No Description Price (each) Stock
FY114047 NUT (NON HAZ) $3.03 IN STOCK
Photo Part No Description Price (each) Stock
FY110056 NUT $4.27 IN STOCK
Photo Part No Description Price (each) Stock
RNS000041 PLATE (NON HAZ) $7.24 IN STOCK
Photo Part No Description Price (each) Stock
LR015002 WASHER (NON HAZ) $15.54 To Order
RNS500010 WASHER - DAMPER LOCKING (NON HAZ) $4.44 IN STOCK
Photo Part No Description Price (each) Stock
LR014955 SPACER $30.06 To Order
Photo Part No Description Price (each) Stock
LR018170 SPRING (NON HAZ) $813.41 To Order
Photo Part No Description Price (each) Stock
LR016411 SPRING (NON HAZ) $813.48 To Order
Photo Part No Description Price (each) Stock
LR015407 SPRING (NON HAZ) $129.61 To Order
RPM500200 BOOT (NON HAZ) $89.28 To Order
Photo Part No Description Price (each) Stock
RPC500030 DAMPER (NON HAZ) $17.56 To Order
Photo Part No Description Price (each) Stock
LR018192 KIT - ELECTRICAL PARTS ( NON HAZ) $134.76 To Order
Photo Part No Description Price (each) Stock
LR018171 KIT - DAMPER SEALS (NON HAZ) $41.09 To Order
Photo Part No Description Price (each) Stock
LR016412 KIT (NON HAZ) $34.25 IN STOCK
Photo Part No Description Price (each) Stock
LR015018 SHOCK ABSORBER $1,749.50 To Order
LR015020 SHOCK ABSORBER $1,749.50 To Order
LR020000 SHOCK ABSORBER $1,749.50 To Order
...and 5 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR016420 DAMPER (NON HAZ) $1,292.52 To Order
LR016419 SHOCK ABSORBER (NON HAZ) $1,292.52 To Order
LR016418 DAMPER $916.75 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR015405 DAMPER $1,749.50 To Order
LR016164 KIT - SHOCK ABSORBER $1,749.50 To Order
LR023431 KIT - SHOCK ABSORBER $1,749.50 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR016425 DAMPER (NON HAZ) $673.86 To Order
LR016424 DAMPER (NON HAZ) $642.90 To Order
LR016423 DAMPER (NON HAZ) $673.86 To Order
View All
Rear Springs And Shock Absorbers ((V) FROMAA000001) of Land Rover Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HC1 LR014904
CLIP - WIRING ( NON HAZ)
With Continuous Variable Damping / Connector / From: AA000001 		$2.40 2
HC2 LR015001
CLIP
With Continuous Variable Damping / Shock Absorber / From: AA000001 		$1.11 2
HN1 FY114047
NUT (NON HAZ)
Flanged, Locking, M14 / From: AA000001
IN STOCK 		$3.03 2
HN2 FY110056
NUT
M10 / From: AA000001
IN STOCK 		$4.27 6
HW1 RNS000041
PLATE (NON HAZ)
Bump Washer / From: AA000001
IN STOCK 		$7.24 2
HW2 LR015002
WASHER (NON HAZ)
With Continuous Variable Damping / Shock Absorber / From: AA000001 		$15.54 2
HW2 RNS500010
WASHER - DAMPER LOCKING (NON HAZ)
Less Adaptive Damping /
IN STOCK 		$4.44 2
HW3 LR014955
SPACER
With Continuous Variable Damping / Shock Absorber / From: AA000001 		$30.06 2
5A669A LR015018
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: AA000001 / To: AA216111 		$1,749.50 1
5A669A LR015020
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: AA000001 / To: AA216111 		$1,749.50 1
5A669A LR020000
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: AA216112 / To: AA243562 		$1,749.50 1
5A669A LR020001
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: AA216112 / To: AA243562 		$1,749.50 1
5A669A LR023234
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: AA243563 / To: CA726369 		$1,889.46 1
5A669A LR023235
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: AA243563 / To: CA726369 		$1,889.46 1
5A669A LR032651
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: CA726370 		$1,564.62 1
5A669A LR032652
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: CA726370
IN STOCK 		$1,006.47 1
5A669B LR016420
DAMPER (NON HAZ)
3.6L V8 32V DOHC EFi Diesel Lion, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Complete Module Assy / From: AA000001 / To: AA999999 		$1,292.52 2
5A669B LR016419
SHOCK ABSORBER (NON HAZ)
3.0L 24V DOHC V6 TC Diesel, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Complete Module Assy / From: AA000001 		$1,292.52 2
5A669B LR016418
DAMPER
Less ACE Suspension, Less Adaptive Damping, Less Roll Stability Control / Complete Module Assy / From: AA000001 / To: CA758725 		$916.75 2
5A669B LR041110
MACPHERSON STRUT
Less ACE Suspension, Less Adaptive Damping, Less Roll Stability Control / Complete Module Assy / From: CA758726 		$1,103.11 2
5A669C LR015405
DAMPER
With Continuous Variable Damping / RH, Service Kit / From: AA000001 / To: AA247351 		$1,749.50 1
5A669C LR016164
KIT - SHOCK ABSORBER
With Continuous Variable Damping / LH, Service Kit / From: AA000001 / To: AA247351 		$1,749.50 1
5A669C LR023431
KIT - SHOCK ABSORBER
With Continuous Variable Damping / LH, Service Kit / From: AA247352 		$1,749.50 1
5A669C LR023436
DAMPER
With Continuous Variable Damping / RH, Service Kit / From: AA247352 		$1,794.35 1
5A669D LR016425
DAMPER (NON HAZ)
3.6L V8 32V DOHC EFi Diesel Lion, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Includes Seal, Service Kit / From: AA000001 / To: AA999999 		$673.86 2
5A669D LR016424
DAMPER (NON HAZ)
3.0L 24V DOHC V6 TC Diesel, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Includes Seal, Service Kit / From: AA000001 		$642.90 2
5A669D LR016423
DAMPER (NON HAZ)
Less ACE Suspension, Less Adaptive Damping, Less Roll Stability Control / Includes Seal, Service Kit / From: AA000001 		$673.86 2
5B752 LR015407
SPRING (NON HAZ)
With Continuous Variable Damping / From: AA000001 		$129.61 2
5B752 RPM500200
BOOT (NON HAZ)
Less Adaptive Damping / From: AA000001 		$89.28 2
5K502 RPC500030
DAMPER (NON HAZ)
From: AA000001 		$17.56 2
14N424 LR018192
KIT - ELECTRICAL PARTS ( NON HAZ)
With Continuous Variable Damping / From: AA000001 		$134.76 2
5560A LR018170
SPRING (NON HAZ)
With Continuous Variable Damping / Service Kit / From: AA000001 		$813.41 2
5560B LR016411
SPRING (NON HAZ)
Less Adaptive Damping / Service Kit / From: AA000001 		$813.48 2
58702A LR018171
KIT - DAMPER SEALS (NON HAZ)
With Continuous Variable Damping / Includes O-Rings, Spacers And A Nut / From: AA000001 		$41.09 2
58702B LR016412
KIT (NON HAZ)
Less Adaptive Damping / Includes O-Rings, Spacers And A Nut / From: AA000001
IN STOCK 		$34.25 2
