Heater/Air Cond.external Components ((V) Fromaa000001)

Land Rover Discovery 4 (2010-2016) [3.0 DOHC GDI SC V6 Petrol]

Find Your Part

Land Rover Discovery 4 (2010-2016) [3.0 DOHC GDI SC V6 Petrol] - Heater/Air Cond.External Components ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
MYP100500L SCREW $1.22 To Order
Photo Part No Description Price (each) Stock
JTF000052 SENSOR - AIR COND. AMBIENT AIR $25.03 To Order
Photo Part No Description Price (each) Stock
JTF000060 SENSOR - HEATER TEMPERATURE CONTROL $119.79 To Order
JTF500010 SENSOR - HEATER TEMPERATURE CONTROL $39.87 To Order
Photo Part No Description Price (each) Stock
JUB500170 TUBE - WATER DRAIN $7.94 To Order
Photo Part No Description Price (each) Stock
YDB500090 SENSOR - AIR POLUTION $146.57 To Order
LR034133 SENSOR - AIR POLUTION $69.56 To Order
View All
Heater/Air Cond.External Components ((V) FROMAA000001) of Land Rover Land Rover Discovery 4 (2010-2016) [3.0 DOHC GDI SC V6 Petrol] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HS1 MYP100500L
SCREW
6 X 26 / From: AA000001 		$1.22 1
12A647 JTF000052
SENSOR - AIR COND. AMBIENT AIR
Pollution Sensor / From: AA000001 		$25.03 1
18C340 JTF000060
SENSOR - HEATER TEMPERATURE CONTROL
(+)"J", With Humidity Sensor / From: AA000001 		$119.79 1
18C340 JTF500010
SENSOR - HEATER TEMPERATURE CONTROL
(-)"J", Less Humidity Sensor / From: AA000001 		$39.87 1
19A786 JUB500170
TUBE - WATER DRAIN
Evaporator Drain / From: AA000001 		$7.94 2
19E702 YDB500090
SENSOR - AIR POLUTION
(+)"J", ATC Air Conditioning, With Pollution Sensor / Pollution Sensor / From: AA000001 / To: CA612098 		$146.57 1
19E702 LR034133
SENSOR - AIR POLUTION
(+)"J", ATC Air Conditioning, With Pollution Sensor / Pollution Sensor / From: CA612099 		$69.56 1
