Name: Transfer Drive Components (8 Speed Auto Trans ZF 8HP70 4WD, With 2 Spd Trans Case With Ctl Trac) ((V) FROMEA000001)
Rating: 4.4 (1 reviews)

Transfer Drive Components (8 Speed Auto Trans ZF 8HP70 4WD, With 2 Spd Trans Case With Ctl Trac) ((V) FROMEA000001) of Land Rover Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC]

View All

Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC] - Transfer Drive Components (8 Speed Auto Trans ZF 8HP70 4WD, With 2 Spd Trans Case With Ctl Trac)...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	IZB500040	RING - SEALING	$19.08	To Order

Photo	Part No	Description	Price (each)	Stock
	IZB500050	RING - SEALING	$22.26	To Order

Photo	Part No	Description	Price (each)	Stock
	XYP500230	SCREW	$0.74	To Order

Photo	Part No	Description	Price (each)	Stock
	FS106166	SCREW	$1.22	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	IYF500030	WASHER	$0.99	To Order

Photo	Part No	Description	Price (each)	Stock
	LR051738	BRACKET - ELECTRICAL UNIT	$13.62	IN STOCK
	LR051739	BRACKET - ELECTRICAL UNIT	$13.62	To Order

Photo	Part No	Description	Price (each)	Stock
	IYB500020	PLUG - OIL DRAIN	$5.15	To Order

Photo	Part No	Description	Price (each)	Stock
	IYX500050	KIT - GREASE AND ORING	$24.99	To Order

Photo	Part No	Description	Price (each)	Stock
	LR105429	KIT - TRANSFER CASE CLUTCH	$683.93	To Order

Photo	Part No	Description	Price (each)	Stock
	LR052217	COVER - MODULE	$13.62	To Order

Photo	Part No	Description	Price (each)	Stock
	LR053307	MODULE - TRANSFER SHIFT CONTROL	$402.55	To Order

Photo	Part No	Description	Price (each)	Stock
	IGH500040	MOTOR - TRANSFER CASE	$746.27	To Order

Photo	Part No	Description	Price (each)	Stock
	IGF500011	SOLENOID - ELECTRONIC PRESSURE CTL	$176.86	To Order

Photo	Part No	Description	Price (each)	Stock
	IZB500030	SEAL - TRANSFER BOX	$29.43	To Order

Photo	Part No	Description	Price (each)	Stock
	IAB500191	SENSOR - TRIPMINDER	$175.75	To Order

Photo	Part No	Description	Price (each)	Stock
	LR086059	FLANGE - PROPSHAFT	$200.79	To Order
	LR086059	FLANGE - PROPSHAFT	$200.79	To Order

Photo	Part No	Description	Price (each)	Stock
	LR039528	KIT - TRANSFER BOX FLANGE	$255.69	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HR1	IZB500040	RING - SEALING	IZB500040 RING - SEALING Front Output, Seal / From: EA000001	$19.08	1
HR2	IZB500050	RING - SEALING	IZB500050 RING - SEALING Rear Output, Seal / From: EA000001	$22.26	1
HS1	XYP500230	SCREW	XYP500230 SCREW 4 X 16MM / From: EA000001	$0.74	2
HS2	FS106166	SCREW IN STOCK	FS106166 SCREW Hexagonal Head, M6 X 16MM / From: EA000001 IN STOCK	$1.22	2
HW1	IYF500030	WASHER	IYF500030 WASHER M16, Plug - Oil Drain / From: EA000001	$0.99	2
7A010	IYB500020	PLUG - OIL DRAIN	IYB500020 PLUG - OIL DRAIN Filler Plug, M16, Plug - Oil Drain / From: EA000001	$5.15	2
7B214A	LR086059	FLANGE - PROPSHAFT	LR086059 FLANGE - PROPSHAFT Front, Propshaft / From: EA000001 / To: GA820873	$200.79	1
7B214A	LR086059	FLANGE - PROPSHAFT	LR086059 FLANGE - PROPSHAFT Front, Propshaft / From: GA820874	$200.79	1
7B214B	LR039528	KIT - TRANSFER BOX FLANGE	LR039528 KIT - TRANSFER BOX FLANGE Propshaft, Rear / From: EA000001	$255.69	1
7B216	IYX500050	KIT - GREASE AND ORING	IYX500050 KIT - GREASE AND ORING Input Shaft, Kit / From: EA000001	$24.99	1
7B668	LR105429	KIT - TRANSFER CASE CLUTCH	LR105429 KIT - TRANSFER CASE CLUTCH From: EA000001	$683.93	1
7D027	LR052217	COVER - MODULE	LR052217 COVER - MODULE Module - Transfer Case Shift Control / From: EA000001	$13.62	1
7E453	LR053307	MODULE - TRANSFER SHIFT CONTROL	LR053307 MODULE - TRANSFER SHIFT CONTROL From: EA000001	$402.55	1
7G360	IGH500040	MOTOR - TRANSFER CASE	IGH500040 MOTOR - TRANSFER CASE Transfer Case Shifter / From: EA000001	$746.27	1
7G383	IGF500011	SOLENOID - ELECTRONIC PRESSURE CTL	IGF500011 SOLENOID - ELECTRONIC PRESSURE CTL Transfer Box / From: EA000001	$176.86	1
7H426	IZB500030	SEAL - TRANSFER BOX	IZB500030 SEAL - TRANSFER BOX Input Shaft / From: EA000001	$29.43	1
9E731	IAB500191	SENSOR - TRIPMINDER	IAB500191 SENSOR - TRIPMINDER High/Low Position Sensor / From: EA000001	$175.75	1
2031	LR051738	BRACKET - ELECTRICAL UNIT IN STOCK	LR051738 BRACKET - ELECTRICAL UNIT LHD / Module - Transfer Case Shift Control / From: EA000001 IN STOCK	$13.62	1
2031	LR051739	BRACKET - ELECTRICAL UNIT	LR051739 BRACKET - ELECTRICAL UNIT RHD / Module - Transfer Case Shift Control / From: EA000001	$13.62	1

Transfer Drive Components (8 Speed Auto Trans Zf 8Hp70 4Wd, With 2 Spd Trans Case With Ctl Trac)...

Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC]

Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC] - Transfer Drive Components (8 Speed Auto Trans ZF 8HP70 4WD, With 2 Spd Trans Case With Ctl Trac)...
