Name: Fuel Injectors And Pipes (Cologne V6 4.0 EFI (SOHC)) ((V) FROMAA000001)
Rating: 4.6 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4409298	SCREW	$0.68	To Order

Photo	Part No	Description	Price (each)	Stock
	LR000398	SCREW	$0.59	To Order

Photo	Part No	Description	Price (each)	Stock
	FS105166	SCREW	$0.67	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	FS105087	BOLT	$0.77	To Order

Photo	Part No	Description	Price (each)	Stock
	LR031819	O-RING	$2.36	To Order

Photo	Part No	Description	Price (each)	Stock
	MYF500010	SPACER	$1.41	To Order

Photo	Part No	Description	Price (each)	Stock
	LR004860	INJECTOR	$165.70	To Order

Photo	Part No	Description	Price (each)	Stock
	MHU500090	BRACKET	$6.38	To Order

Photo	Part No	Description	Price (each)	Stock
	1024446	ADAPTOR	$4.92	To Order

Photo	Part No	Description	Price (each)	Stock
	4537688	TUBE - FUEL CROSSOVER	$12.90	To Order

Photo	Part No	Description	Price (each)	Stock
	MAP500120	TUBE - FUEL SUPPLY	$132.50	To Order

Photo	Part No	Description	Price (each)	Stock
	4470435	COVER - FUEL RAIL	$8.49	To Order

Photo	Part No	Description	Price (each)	Stock
	MLH500190	PIPE - FUEL	$214.43	To Order

Photo	Part No	Description	Price (each)	Stock
	LR018782	PIPE - FUEL	$550.87	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	4409298	SCREW	4409298 SCREW M8 X 20MM / From: AA000001	$0.68	4
HS1	LR000398	SCREW	LR000398 SCREW M5 X 12MM / From: AA000001	$0.59	4
HS2	FS105166	SCREW IN STOCK	FS105166 SCREW M5 X 16MM / From: AA000001 IN STOCK	$0.67	3
HS3	FS105087	BOLT	FS105087 BOLT M5 x 8MM / From: AA000001	$0.77	1
2A767	MYF500010	SPACER	MYF500010 SPACER From: AA000001	$1.41	1
9D280	4383892	MANIFOLD - FUEL SUPPLY	4383892 MANIFOLD - FUEL SUPPLY LH / From: AA000001	$37.40	1
9D280	LR000618	MANIFOLD - FUEL SUPPLY	LR000618 MANIFOLD - FUEL SUPPLY RH / From: AA000001	$22.01	1
9E964A	MLH500190	PIPE - FUEL	MLH500190 PIPE - FUEL From: AA000001	$214.43	1
9E964B	LR018782	PIPE - FUEL	LR018782 PIPE - FUEL From: AA000001	$550.87	1
9F593	LR004860	INJECTOR	LR004860 INJECTOR From: AA000001	$165.70	6
9F931	MHU500090	BRACKET	MHU500090 BRACKET From: AA000001	$6.38	1
9G512	1024446	ADAPTOR	1024446 ADAPTOR From: AA000001	$4.92	6
9G624	4537688	TUBE - FUEL CROSSOVER	4537688 TUBE - FUEL CROSSOVER From: AA000001	$12.90	1
9H336	MAP500120	TUBE - FUEL SUPPLY	MAP500120 TUBE - FUEL SUPPLY From: AA000001	$132.50	1
19H488	4470435	COVER - FUEL RAIL	4470435 COVER - FUEL RAIL From: AA000001	$8.49	1
9229	LR031819	O-RING	LR031819 O-RING O Ring / From: AA000001	$2.36	12

Fuel Injectors And Pipes (Cologne V6 4.0 Efi (Sohc)) ((V) Fromaa000001)

Land Rover Discovery 4 (2010-2016) [4.0 Petrol V6]
